111172 IC-S411-ML-0-10V-BW

< Back

2.45 x 0.74 x 0.2 in [62.2 x 19.0 x 8.1 mm]

WT: 0.009 kg

Product description

Doppler radar with digital algorithm for motion & micro-motion detection
High-gain microstrip antenna with low sidelobes and less back radiation
Strong penetration through glass, plastic, fabric, ceramic, thin wood, etc.
Supports 4-position DIP switch for function adjustment
Equipped with ambient light detection capability
Mounting height up to 5 meters
0-10 V Control Output

Swipe for more

Operating voltage:	12 VDC ± 10 %
Standby Power:	Typ. 0.24 W @ 12 V
Power supply type:	Drive separated supply
PIR axial distance (mounting height):	Max 5 m
Horizontal -3dB beamwidth/E-Plane:	105°
Vertical -3dB beamwidth/H-Plane:	105°
Type of installation:	Luminaire integration

Product name

Power Supply

Detection technology

Mounting

height

Dimensions (L x W x H)

IC-S411-ML-0-10V-BW

12 VDC

PIR + Ambient Light Sensor

5 m

62.2 x 19.0 x 8.1 mm

Operating temperature:	-25 ... +70 ℃
Storage temperature:	-40 ... +85 ℃
Working humidity:	10 ... 90 %
Store humidity:	5 ... 95 %
Operating environment:	/
Maximum Tc temperature:	/
